Description
The best Edge Bander in the USA.
LARGE PLATE SUPPORT
Fits edge tape rolls up to 20”
ADJUSTABLE GUIDE
Supports the edgebanding tape while it is being applied to the workpiece.
TAPE GUIDE
Ensure the alignment between the tape and workpiece.
TABLE GUIDE
Provides a smooth surface allowing the workpiece to slide across the table.
FOLDABLE LEGS
Can be easily transported from the shop to the job site.
GLUE ASSEMBLY
Has a recycle system that allows excess glue to flow back into the glue pot.
| Technical Information | CBC.E |
|---|---|
| Electrical specs | 1 Phase 110 V 1500 W 60Hz |
| Motor specs | 24 V 10 Amp |
| Manual Feeding Speed | 18ft/min |
| Max edgebanding Height | 3″ |
| Edgebanding Coil Support Diameter | 19 1/2″ |
| Tape Thickness | 0.4 – 2mm |
| Edgebanding Material | Melamine /PVC/ABS/PP/ VEENER non-fleeced |
| Glue Pot Capacity | 1.5 lbs |
| Recommended Glue Temperature Range | 130° to 180º C |
| Glue Pot Tape | Granulated Hot-Melt |
| Max. Machine Dimension | 47″ x 31″ x 42″ |
| Shipping Dimension | 32″ x 22″ x 20″ |
| Weight | 114 Lbs. |
| Warranty | 2 years |
Certified CE – Global
Machinery Directive 2006/42/EC
Electromagnetic Compatibility Directive 2014/30/EU
RoHS Directive 2011/65/EU
Certified UL USA – CAN
E490869
Top Selling Edge Bander in the USA
2018-2019
Top Selling Edge Bander in Brazil
2018-2019
https://youtu.be/VuxwoKBELAohttps://youtu.be/oGPVNxMS4ZIhttps://youtu.be/ALEjZ5x-2yYhttps://youtu.be/17rjVG02CsAhttps://youtu.be/4UZj0wMJlN0https://youtu.be/sxViQ2-D7JIhttps://youtu.be/u0yVSjbBMeghttps://youtu.be/n0srXWnTTA8https://youtu.be/tPTY2ZMpNkwhttps://youtu.be/KduTiBjo2lAhttps://youtu.be/hvK0tGI2RBM
| Technical Info | CBC Flex | CBC.E | CBC.MR | CBC/2.MR | CBC.T | CBC.P |
|---|---|---|---|---|---|---|
| Eletrical specs | 1 Phase 110V 550W 60Hz | 1 Phase 110V 1500W 60Hz | 1 Phase 110V 1500W 60Hz | 1 Phase 110V 1500W 60Hz | 1 Phase 220V 60Hz 30A | 1 Phase 220V 60Hz 30A |
| Feeder Speed | 0-19 ft/min | 0-18 ft/min | 0-26 ft/min | 0-26 ft/min | 0-16ft/min | 23ft/min |
| Edgebanding Thickness | 0.4 – 1mm | 0.4 – 2mm | 0.4 – 2mm | 0.3 – 2mm | 0.4 – 3mm | 0.4 – 3mm |
| Glue Temperature | 130° to 180° C | 130° to 180° C | 130° to 180° C | 130° to 180° C | 180° to 210° C | 180° to 210° C |
| Glue Pot Type | Low Temp. Granulated Hot-Melt EVA | Low Temp. Granulated Hot-Melt EVA | Low Temp. Granulated Hot-Melt EVA | Low Temp. Granulated Hot-Melt EVA | High Temp. Granulated Hot-Melt EVA | Granulated Hot-Melt EVA / PUR |
| Workarea | – | 39 3/8″ x 15 3/4″ | 101 3/4″ x 15 3/4″ | 101 3/4″ x 15 3/4″ | 78 3/4″ x 10 2/5″ | 112″x34″ |
| Max Edgebanding Height | 1/2″ to 1 7/8″ | 3″ | 3″ | 3″ | 2″ | 2″ |
| Panel Thickness | 1/2″ to 1 7/8″ | 3″ | 3″ | 3″ | 12-45mm | 10-50mm |
| Weight | 21 Lbs | 114 Lbs | 242.5 Lbs | 330 lbs | 1025 Lbs | 1719 Lbs |
| Machine Dimension | 11″ x 14″ x 13 1/2″ | 47″ x 31″ x 42″ | 101 3/4″ x 35 1/2 x 43″ | (101 3/4″) 58″ x 43″ x 43″ | 112″ x 63″ x 51″ | 112″ x 156″ x 49″ |
| End Trim | – | Manual | Manual | Manual | Pneumatic | Pneumatic |
Instructions
Download the Manual
The Glue Recommendation
Download The Glue Recommendation
