DTX.480
DOVETAIL MACHINE
~40-50 boxes per hour
•
strongest joints
•
3 cycles speeds
Automatic dovetail machine, 40-50 drawer boxes per hour
The Maksiwa DTX.480 Dovetail Machine is designed to deliver strong, precise, and visually appealing dovetail joints with high production efficiency. Built for professional cabinet shops, it produces both pins and tails with exceptional accuracy, ensuring perfect joint fit and superior finish quality.
With a robust industrial structure, high-speed spindle, and pneumatic clamping system, the DTX.480 enables fast setup and consistent results across a wide range of materials, including solid wood and plywood. Its user-friendly controls and repeatable adjustments allow operators to maximize productivity while maintaining precision in every cycle.
Ideal for drawer box manufacturing, the DTX.480 combines durability, speed, and ease of operation to enhance workflow and elevate the quality of your finished products. Produces up to 40–50 drawer boxes per hour.
xxxxx
- All-in-one Boring & Insertion
- 1.5 HP motor
- 35mm hinge cup boring
- Multiple drilling patterns
- Quick-set boring distance
- Integrated dust collection
- Compact design
- Ideal for cabinetry, and furniture
*Bits not included.
PRECISION DOVETAILING FOR HIGH-PRODUCTION CABINET SHOPS
WHY CHOOSE DTX.480?
VIDEO
INSTALLATION
2 YEAR
EXTENDED WARRANTY
US BASED
TECH SUPPORT
REAL REVIEWS. REAL RESULTS
DTX.480 - MACHINE SPECIFICATIONS
| Technical Information | DTX.480 |
|---|---|
| Electrical Specs | 3 Phase 220V 12.5 Amps 60 Hz (3 kw) |
| Spindle Motor Specs | 2 HP 21,500 RPM |
| Spindle Collet Capacity | 12mm |
| Fixed Pitch | 25mm |
| Feed Motor | 2 HP |
| Spindle Vertical Adjustment | 30mm |
| Pneumatic Clamp | 2 Horizonal | 2 Vertical |
| Maximum Material Length | 1500 mm | 59″ |
| Maximum Material Width | 480 mm | 19″ |
| Vertical Material Thickness Capacity | 10 – 30 mm | 0.4″ – 1.18″ |
| Horizontal Material Thickness Capacity | 10 – 35 MM | 0.4″ – 1.377″ |
| Tenon Thickness Min/Max | 10 – 20 mm | 0.4 – 0.78″ |
| Tenon Width Min/Max | 10 – 18 mm | 0.4″ – 0.70″ |
| Tenon Depth Min/Max | 10 – 20 mm | 0.4 – 0.78″ |
| Dust Collection Port | 100 mm | 4″ |
| Air Pressure Requirement | 6 Bar | 90 PSI |
| Machine Dimension | 50″ x 31″ x 52″ |
| Weight | 1058lbs |
| Warranty | 2 Years |
