Description
Perfect for collecting light powder of small machines.
WHY THE DUST COLLECTOR IS IMPORTANT?
The unhealthy effects caused by wood dust can be dramatically reduced by the use of a dust collector. In 2002 the U.S. government put saw dust on their list of “known carcinogens”, linking it to a variety of nose, throat, and lung cancers, making it an official health risk. Collecting and exhausting dust at its source, before it reaches you, is the most efficient way to deal with wood dust. That’s why woodworking machines — from table saws to disk sanders — come with exhaust hoods or ports.
| Technical Information | CP/2.C |
|---|---|
| Motor Specs | 1 Phase 220V 2HP 15 Amps 60Hzs |
| Air Flow capacity | 1490 CFM |
| Fan Diameter | 12″ | 305mm |
| Bag Capacity | 5ft3 |
| Number of air intel | 2 |
| Inlet size | Main:5″ |125mm – Spliter: 4″ | 100mm |
| Filtration | 1 micron |
| Sound Rating | 89 dB |
| Weight | 95 Lbs | 43kg |
| Warranty | 2 years |
https://youtu.be/oYzhaHjC5X8https://youtu.be/rPI_yS1emTI
Instructions
Download the Manual
Certificates
Certified CE – Global
Jonh Terry
Wood StudioI use this for collecting dust from my chop saw and it works well. The key is to build a box behind the saw an suck out the dust from the botton. Works very well.
Phil Jackson
Maderas WorkingI have a small shop, 3 car garage and have had this around a year. Not one problem in it’s operation, works great. Now that being said as far as the packaging goes, this is not good at all. I read where other buyers where saying parts bent and so on. I was lucky I only had one dent in the sheel metal.
Ronnie Lewis
Lewis WoodworkThis dust collector is adequate for my purposes. I do some occasional hobby work in my basement workshop. This item helps keep dust to a manageable level. Good purchase.
| Technical Information | CP/1.C | CP/2.C | CPD/3.C | CPD/5.S | CY/3.C |
|---|---|---|---|---|---|
| Motor | 1 HP – 1 Phase | 2 HP – 1 Phase | 3 HP – 1 Phase | 5 HP – 3 Phase | 3HP – 1 phase |
| Motor Amp Draw | 1 Phase – 127 V – 16 A or 220 V – 8 A | 1 Phase – 220 V – 15A | 1 Phase – 220 V – 15A | 3 Phase – 220 V – 17 A | 1 Phase 220V 3HP 15A |
| Air suction capacity | 600 ft³/min | 1,790 ft³/min | 2,760 ft³/min | 3,001 ft³/min | 1941 CFM |
| Bag volume | 60 L (2,12 ft³) | 153 L (5,4 ft³) | 307 L (10,8 ft³) | 400 L (14.13 ft³) | Drum Size -31 Gal |
| Number of air intel | 1 Entry | 2 Entries | 3 Entries | 5 Entries | 3 Entries |
| Bag size | 13 x 25 inches | 18 x 34 inches | 18 x 34 inches | 23-5/8 x | 20″ x 43″ |
| Weight | 73 Lbs | 106 Lbs | 130 Lbs | 242.5 Lbs | 181 lbs |
| Micro rating | 2.5 microns | 1 microns | 1 microns | 2.5 microns | 1 microns |
